AISI 304 Stainless Steel. Load cell in Stainless Steel. IP67 protection rating.

Precision class C3, C3MR.

Category:

Description

The TE Single Cell Platform

Small and medium capacity electronic platforms, having a precise and sturdy structure, are particularly suitable for all types of industrial and commercial applications in which it’s necessary to work in environments with strict hygiene requirements.



MAIN FEATURES

  • Functions with an approved “single point” STAINLESS STEEL load cell according to OIML R60 standards with protection against dust and water splashes according to IP67 standards.
  • Structure with tubulars, mechanics, trinkets and loading surface in AISI304 satin finish stainless steel.
  • Fitted with adjustable STAINLESS steel feet with plastic resting surface and level.
  • Up to 15 Vdc power supply.
  • Shielded 3m connection cable with connectors (IP65) for connection to the indicator.

OPTIONS FOR ATEX VERSION

  • CCATEX: ATEX certificate for each load cell.
  • DCATEXMECH: ATEX declaration for the PLATFORM (for the load cells ATEX declaration see CCATEX-1 code). Option to be offered only if the platform is ordered without the indicator, if so, refer to the chosen weight indicator available certifications.

AVAILABLE UPON PRICE ESTIMATE

  • Special sizes and capacities.
  • Structure in AISI316 stainless steel.
  • Fully-welded IP68/IP69K stainless steel load cell, specific for use in wet environments.
