PBI Series

PBI Series

PBI Series

Stainless Steel. Load cell in Aluminium. IP65 protection rating.

Precision class C3.

Category:

Description

The PBI Series Single Cell Platform

Small and medium capacity electronic platforms with a stainless steel surface having a precise and sturdy structure. Suitable for creating scales and automatic weight checking systems for all industrial and commercial applications. The standard version is provided with approved load cell.



TECHNICAL FEATURES

  • Functions with a “single point” 350 Ohm aluminium load cell, in stainless steel hermetic cover, approved according to OIML R60 C3 standards (3000 divisions), IP65 protection degree.
  • Stainless steel tubular structure, with adjustable resting feet and level.
  • Fitted with stainless steel loading surface.
  • Up to 15 Vdc power supply.3m shielded cable for connection to the indicator.
  • Upon request:
    – platform calibration service with weight indicator;
    – 3000e CE-M approval, to be combined always to the calibration service;
    – support column for indicator.
